Trough Cable Tray
Solid Bottom Cable Tray Systems for Enclosed and Protected Cable Routing
IEC 61537 Compliant
Available in Multiple Load Classes and Material Options
Compatible with Complete Cable Tray Support and Accessory Systems
Solid bottom cable tray systems are designed for applications requiring enhanced cable protection, environmental isolation, and organized cable routing.
The fully enclosed structure provides protection against dust, debris, moisture, and accidental mechanical damage while offering improved electromagnetic shielding for sensitive control, instrumentation, and communication cables.
The system is available in multiple dimensions, material grades, and enclosure configurations, and can be supplied together with compatible fittings, support systems, and accessories as a complete cable management solution.
Why Solid Bottom Cable Tray?
Designed for projects requiring maximum cable protection, environmental control, and organized cable routing.
Ideal for Projects Requiring
Sensitive control and instrumentation cable protection
Dust-controlled or clean operating environments
Concealed cable routing
Enhanced cable protection against external damage
Improved electromagnetic shielding performance
Key Benefits
Fully enclosed cable protection
Improved environmental isolation
Reduced electromagnetic interference (EMI)
Clean and organized cable routing
Suitable for commercial, industrial, and cleanroom applications
Application-Oriented Configurations
Designed for environments requiring contamination control, cleanliness, and enhanced cable protection.
Typical Configuration
Fully Enclosed Structure
Width: 100–600 mm
Optional Gasket Sealing
Covered System Design
Common Applications
Hospitals
Pharmaceutical Plants
Clean Rooms
Laboratories
Food Processing Facilities
Why This System
Protects cables from dust and contaminants
Supports hygienic operating requirements
Maintains clean environment standards
Easy cleaning and maintenance
Designed for installations where signal integrity and electromagnetic protection are critical.
Typical Configuration
Steel Solid Bottom Tray
Tight-Fitting Cover
Optional Grounding Design
Optional Bonding Accessories
Common Applications
Control Rooms
Instrumentation Systems
Communication Networks
Process Automation Facilities
Electrical Control Centers
Why This System
Helps reduce electromagnetic interference
Improves signal reliability
Protects sensitive communication circuits
Supports stable automation system performance
Designed for visible installations where appearance, organization, and cable concealment are important.
Typical Configuration
Powder-Coated Finish
Custom Color Options
Integrated Cover Design
Common Applications
Commercial Buildings
Office Facilities
Airports
Shopping Centers
Public Buildings
Why This System
Concealed cable routing
Improved visual appearance
Clean architectural integration
Customizable project aesthetics
Engineered for industrial environments where cables require enhanced mechanical protection.
Typical Configuration
Thickness: 1.5–2.5 mm
Reinforced Cover Design
Heavy-Duty Structural Configuration
Common Applications
Factories
Industrial Plants
Equipment Areas
Manufacturing Facilities
Utility Infrastructure
Why This System
Protects cables from impact and damage
Improves cable system reliability
Suitable for harsh industrial environments
Long service life
Designed for environments where corrosion resistance and environmental protection are required simultaneously.
Material Options
Hot-Dip Galvanized Steel (HDG)
Stainless Steel 304
Stainless Steel 316L
Common Applications
Chemical Plants
Wastewater Facilities
Coastal Projects
Marine Installations
Utility Infrastructure
System Characteristics
Product Selection Reference
Typical Configuration Guide
| Project Requirement | Recommended Configuration |
| Clean environments and contamination control | Clean Environment System |
| Control and instrumentation cables | EMI-Sensitive System |
| Architectural and exposed installations | Architectural System |
| Heavy-duty cable protection | Industrial Protection System |
| Corrosive environments | Stainless Steel Solid Bottom System |
Configuration selection may vary according to environmental conditions, cable type, protection requirements, and support spacing.
Engineering Design Range
Structural Configuration
| Item | Specification |
| Structure Type | Fully Enclosed Tray |
| Cover Type | Clip-On / Screw-Fixed |
| Optional Sealing | Gasket Sealing Available |
General Dimensions
| Item | Specification |
| Width | 50–1000 mm |
| Height | 50–300 mm |
| Standard Length | 2000 / 3000 mm |
| Material Thickness | 0.8–2.5 mm |
Load Performance
| Item | Specification |
| Standard | IEC 61537 |
| Test Span | 1.5–2.5 m |
| Deflection Limit | L/200 |
| Light Duty Load | 50–120 kg/m |
| Medium Duty Load | 120–250 kg/m |
Actual load performance depends on tray dimensions, material thickness, cover reinforcement, and support spacing.
Material and Surface Finish Options Pre-Galvanized Steel (GI) Hot-Dip Galvanized Steel (HDG) Powder Coated Steel
Stainless Steel 304 Stainless Steel 316L
Environmental Protection
| Configuration | Protection Level |
| Without Gasket | IP40 |
| With Gasket Sealing | Up to IP54 |
Protection level depends on enclosure configuration and installation conditions.
Typical Applications
Solid bottom cable tray systems are commonly used in:
Hospitals and Healthcare Facilities
Pharmaceutical Manufacturing Plants
Laboratories and Research Facilities
Commercial Buildings
Airports and Transportation Infrastructure
Data and Communication Centers
Control and Automation Systems
Food Processing Facilities
Industrial Manufacturing Plants
Utility Infrastructure Projects
Complete Cable Management System
Compatible with:
Horizontal Elbows
Vertical Bends
Tees
Crosses
Reducers
Covers
Gasket Sealing Systems
Splice Plates
Support Brackets
Ceiling Suspended Supports
Wall-Mounted Supports
Strut Channel Framing Systems
Related Cable Tray Systems
| Project Requirement | Recommended System |
| Sensitive control and communication cables | Solid Bottom Cable Tray |
| General-purpose cable routing | Perforated Cable Tray |
| Heavy power cable installation | Ladder Cable Tray |
| Frequent cable modifications | Wire Mesh Cable Tray |
Proven in Commercial and Industrial Projects
Solid bottom cable tray systems are widely used in:
Healthcare Facilities
Pharmaceutical Plants
Commercial Buildings
Airports and Transportation Projects
Industrial Automation Systems
Clean Environment Facilities
View Project References
Technical Documentation
The following engineering documents are available through the Engineering Support Center:
Product Data Sheet
Load and Span Tables
CAD Drawings
BIM Models
Installation Manual
Material and Finish Information
Test Reports
Compliance Certificates
Technical Documentation
Engineering Support
Engineering Support
Our engineering team can provide:
Cable Tray System Design Support
Load Calculation Assistance
Span Optimization
Material Selection Guidance
Environmental Protection Recommendations
Project-Specific Customization
Tender and Specification Support
Contact Technical Team
More Details
Detailed technical information, project-specific configurations, environmental protection requirements, and engineering documentation can be provided according to project requirements.
